Ultra trace level (ng/mL) determination of As, Sb, Bi, Zn, Cd, Hg, Ge, Sn, Pb, Se and Te.
-
Double channels / triple channels, two elements / three elements determination simultaneously.
-
Upgradable to atomic fluorescence speciation analyzer.
-
Especially suitable for geologic samples, simultaneous analysis of As, Sb & Bi (AF-630A).
Features
Light Source System
Single-cathode or double-cathode hollow cathode lamp can be used as the light source. - Pulse power supply mode for higher stability and lower drift.
Main current and auxiliary current of double-cathode HCL are automatically matched by PC.
Optical System
Short focal length, non-dispersive, and light close optical system
Advanced gas-liquid separator, with higher signal-to-noise ratio
- Comparable performance with Nafion drier
Anti-foaming design, especially suitable for ion pair separation method- Waste liquid auto drain design, no peristaltic pump is necessary
Low temperature atomization technique
Argon-hydrogen flame auto ignition
Stable temperature control system- Very high stability atomization efficiency
Long life (3 years) and high efficiency (70%) active and recycling mercury trap
Powerful function and upgrading capability
Adding PDI-10 UV digestion device and work station, and coupled with chromatographs realizes speciation analysis of As, Hg, and Se.- Adding WM-10 Ultra-trace Hg determination device to determine directly the ultra-trace Hg in water samples of surface water, sea water, tap water and source water, etc.
Adding VM-10 Gaseous Hg determination device to determine directly the ultra-trace Hg in gas sample of air, natural gas, laboratory and working environment, etc.- Two kinds of autosamplers available for fully automatic operation.
Analytical Results of GSD(sediment) and GSS(soil) Certified Reference Materials (CRM) by AF-630A
|
CRM
|
|
As (μg/g)
|
Sb (μg/g)
|
B (μg/g)
|
|||||||
|
Results
|
Average
|
Certified result
|
Results
|
Average
|
Certified result
|
Results
|
Average
|
Certified result
|
|||
|
GSD-2
|
GSD-2-1
|
5.53
|
5.6
|
5.3～7.1
|
0.42
|
0.41
|
0.29～0.63
|
1.62
|
1.63
|
1.47～1.81
|
|
|
GSD-2-2
|
5.57
|
0.41
|
1.66
|
||||||||
|
GSD-2-3
|
5.82
|
0.41
|
1.59
|
||||||||
|
GSD-3
|
GSD-3-1
|
15.11
|
15.4
|
14.6～20.6
|
4.75
|
4.83
|
4.6～6.2
|
0.70
|
0.70
|
0.65～0.93
|
|
|
GSD-3-2
|
15.56
|
4.82
|
0.72
|
||||||||
|
GSD-3-3
|
15.44
|
4.93
|
0.69
|
||||||||
|
GSD-4
|
GSD-4-1
|
18.83
|
18.7
|
17.1～22.3
|
1.70
|
1.83
|
1.57～2.11
|
0.54
|
0.54
|
0.49～0.79
|
|
|
GSD-4-2
|
19.00
|
1.87
|
0.56
|
||||||||
|
GSD-4-3
|
18.22
|
1.93
|
0.51
|
||||||||
|
GSD-6
|
GSD-6-1
|
12.42
|
12.6
|
12.1～15.1
|
1.06
|
1.06
|
0.92～1.58
|
4.81
|
4.83
|
4.4～5.6
|
|
|
GSD-6-2
|
12.44
|
1.05
|
4.92
|
||||||||
|
GSD-6-3
|
12.93
|
1.08
|
4.76
|
||||||||
|
GSS-1
|
GSS-1-1
|
34.59
|
34.7
|
31.8～35.2
|
0.84
|
0.85
|
0.75～0.99
|
1.18
|
1.18
|
1.11～1.23
|
|
|
GSS-1-2
|
34.91
|
0.87
|
1.15
|
||||||||
|
GSS-1-3
|
34.66
|
0.84
|
1.20
|
||||||||
