| Model# | G103 |
|---|---|
| Force | 50 kN (11,250 lbf) |
| Base Width | 50 mm (2 in) |
| Maximum Span | 170 mm (6.7 in) |
| Minimum Span | 8 mm (0.32 in) |
| Roller | 2, 4, 6, 8, 10 mm (50 mm length standard) |
FEATURES & BENEFITS
- Applications include composites, plastics, metal, medical products, electronics and other materials.
- Modular product construction makes it possible to configure fixtures to specific test requirements.
- Configurations for ASTM, ISO, DIN, EN and other standards available.
- Each fixture features adjustable span lengths, multiple types and sizes of anvils, interchangeable rollers with variety of diameters and lengths. Special anvils for short spans.
- Rollers feature elastic springs and are free to rotate.
- Machine Adapters made to match your test machine attachment points.
