Technical specification
|
Force range |
수직축: 1 gf ~ 30 kgf (10 mN ~ 300 N) 횡축: 2 gf ~ 100 kgf (20 mN ~ 1 kN) |
|
|---|---|---|
|
Force resolution (depending on load cell) |
수직축: 1 gf (10 mN) 횡축: 2 gf (20 mN) |
|
|
Force accuracy |
0.0025 % |
|
|
Testing speed |
0.0001 ~ 10 mm/sec (Max.15mm/sec available on request) |
|
|
Travel range (Testing space) |
Upto 650 mm (500mm with tension sample holder), 1000 mm with Temperature and Humidity Chamber Option |
|
|
Position range setting |
0~500 mm / 700 mm |
|
|
Range resolution |
0.0001 mm |
|
|
Operation modes |
Friction & Scratch (Default) Addionally Tension, Flexural bending (3-point, 4-point), Peel-off (90º and 180º), Compression, Tack, Creep recovery, Loop tack, Stress relaxation, Various kinds of fixtures can be constructed by user demand. |
|
|
Data acquisition rate |
Max. 1000/sec (1000 Hz) |
|
|
Atmosphere |
Lab. condition. Dust and Splash Resistant. |
|
|
Operating temperature |
RT ~ 80℃ (Isothermal) |
|
|
-0℃ ~ 100℃ with optional Temperature and Humidity chamber RT ~ 250℃ with High Temperature Chamber or Hot plate -10℃ ~ 120℃ with Low Tempetature Chamber -40 ~ 100℃ with Cryo option |
||
|
Weight |
17 kg 70 kg with with optional chamber |
|
|
Dimension |
510 mm(W) x 867 mm(H) x 410 mm(D) |
|
|
Elecrical power requirements |
220VAC ±10%, 50/60 Hz |
|
TXA™는 (주)연진에스텍의 등록상표입니다.
